Magnetic Field Line Tube
.jpg)
Product Code : SCL-PLE-11591
The StemAids Magnetic Field Line Tube (also known as a 3D Magnetic Field Chamber) is a specialized educational instrument designed for the empirical study of magnetic flux and the visualization of field lines in three-dimensional space. Optimized for Primary and Secondary STEM curricula, it provides a mess-free, interactive platform for students to observe the complex patterns of magnetism. Manufactured to ISO 9001:2015 standards by Samtech Instruments, this durable system ensures standardized instructional delivery for institutional physics and electromagnetism modules.
Technical Specifications
|
Tender Specification |
OEM Technical Detail |
|
Material Grade |
High-Transparency Acrylic/Polycarbonate Chamber |
|
Visual Media |
Suspended Iron Filings within a specialized viscous fluid or sealed dry chamber |
|
Magnet Compatibility |
Central Inner Chamber accepts bar magnets up to 0.75" (19mm) in diameter |
|
Safety Features |
Fully Sealed System to prevent exposure to loose iron filings |
|
Dimensional Design |
Large-scale chamber optimized for group observation and hands-on pass-around |
|
Functional Principle |
3D Alignment of iron filings along magnetic lines of force |
|
Assembly Mode |
Pre-Configured, Ready-to-Use standalone demonstration unit |
|
ISO Compliance Code |
Manufactured under ISO 9001:2015 Quality Management Systems |
|
HS Code |
9023.00.00 (Educational/Demonstrational Physics Apparatus) |
Key Pedagogical Outcomes (Bloom’s Taxonomy Alignment)
- 3D Flux Visualization -> Facilitates student visualization of magnetic fields as a volume rather than just a 2D plane, supporting Electromagnetism Module 101 (Understanding).
- Magnetic Influence Modeling -> Enables the physical study of how a bar magnet's insertion causes an instantaneous re-alignment of suspended particles (Applying).
- Field Density Analysis -> Supports the Analysis of magnetic field strength near poles versus the center, as indicated by the concentration of iron filings.
- Electromagnetic Application Evaluation -> Allows students to Evaluate the foundational principles used in modern technologies such as MRI, electric motors, and data storage systems (Evaluating).
International Logistics & Compliance
- Packaging: Export-grade ISPM-15 compliant Corrugated box with high-density internal stabilization to prevent scratching or leakage of the transparent chamber.
- Documentation: Includes Manufacturer’s Authorization Form (MAF), Certificate of Conformance (CoC), and English Technical User Guides.
- Durability: Tropicalized design with UV-stabilized transparent materials to prevent chromatic degradation or yellowing over extended institutional lifecycles.
Direct OEM Sourcing Advantages
- Vertical Integration: Total control over the viscosity of the suspension medium and purity of iron filings ensures perfectly clear and repeatable field patterns across bulk rollouts.
- Reliability Protocols: Batch-tested for seal integrity and impact resistance of the outer chamber in high-use educational settings.
- Institutional Support: Guaranteed direct factory availability for replacement magnets and specialized mounting bases ensures maximized asset lifecycle and superior long-term ROI.
