Mini Ray Box
.jpg)
Product Code : SCL-PLE-11561
Quick Answer: The Mini Ray Box is a compact plastic light source that produces a focused beam for ray optics work. Directed at mirrors, lenses or prisms, it shows reflection, refraction and dispersion, running from batteries or a low-voltage supply.
Last updated: 18 October 2026
Key Features
- Produces a clear, focused beam through a light slit.
- Plastic housing with an LED or other light source.
- Used with mirrors, lenses and prisms for reflection and refraction.
- Colour filters can be added to study different colours of light.
Technical Specifications
| Specification | Value |
|---|---|
| Housing | Plastic, with LED or other light source |
| Components | Mini ray box, light slit, lenses; filters optional |
| Power | Battery or low-voltage supply |
| Safety | Avoid direct eye exposure to the beam |
How It Is Used
Place the ray box on a flat surface, switch it on and aim the beam at a mirror, lens or prism. Students trace the incident and emerging rays and measure the angles of incidence and refraction. Do not look directly into the beam.
Frequently Asked Questions
What power does the Mini Ray Box use?
It runs from batteries or a low-voltage supply.
What can be studied with the Mini Ray Box?
Reflection, refraction and dispersion of light, by aiming its beam at mirrors, lenses or prisms and measuring the angles of incidence and refraction.
Related Physics Lab Equipment
See the full physics lab equipment range, or these related ray optics items:
- Ray Box (12v)
- Laser Ray Box
- Ray Optics Kit
- Raybox Colour Filters plastic mounted (Set 6)
- Glass Prism
The Mini Ray Box is available for export to schools and laboratories in Haiti, Mauritius, Iceland, Egypt and Sri Lanka.
For a quotation on the Mini Ray Box, contact JLab India on +91-8569909696.
