Quick Answer:The Capacitance Substitution Box offers 11 preferred capacitor values from 1 µF to 100 µF, chosen with a rotary selector switch, in a 75 x 100 x 40 mm ABS case with two 4 mm safety sockets.
Last updated: 18 October 2026
Key Features
11 easily selectable preferred capacitor values.
Rotary selector switch.
Two 4 mm safety sockets.
Robust ABS case.
Technical Specifications
Specification
Value
Number of capacitors
11
Range
1 µF – 100 µF
Selection
Rotary selector switch
Terminals
Two 4 mm safety sockets
Case
ABS, 75 x 100 x 40 mm
How It Is Used
Connected into a circuit, the box lets students change capacitance quickly, for example to compare charging and discharging times for different values.
Frequently Asked Questions
What capacitance range does the Capacitance Substitution Box cover?
It provides 11 preferred capacitors from 1 µF to 100 µF, selected with the rotary switch.
